Scanner "BLOTrix Reader C1/C1 L" for up to 4 test strips
Scanner "BLOTrix Reader R2 L" for up to 10 test strips
Scanner "BLOTrix Reader S1" for up to 36 test strips
BLOTrix Reader
For evaluation of the results, you can choose between three different reader types, depending on the laboratory size. Each Reader is adapted to the AllergyScreen®/AlleisaScreen® test kit with a panel-specific setcard for perfect clear results and is equipped with a software package for detailed test information.
The BLOTrix Reader with B4C software are manufactured as an IVD by BioSciTec GmbH.
- BLOTrix Reader C1/C1 L - Scans up to 4 test strips at a time BLOTrix Reader R2 L - Scans up to 10 test strips at a time BLOTrix Reader S1 - Scans up to 36 test strips at a time
- Print out and program available in several languages
- Data export via Windows-Excel™ or TXT
- Data import via CSV
- Data transfer to LIMS possible
| BLOTrix Reader C1/C1 L | BLOTrix Reader R2 L | BLOTrix Reader S1 | |
|---|---|---|---|
| Strips scanned at a time | 1—4 test strips | 1—10 test strips | 1—36 test strips |
| Size (w x d x h) | 30 x 23 x 8 cm | 30 x 31 x 8 cm | 60 x 38 x 11 cm |
| Weight | 2.5 kg | 3.1 kg | 16.7 kg |
| Resolution | 1200 x 2400 dpi | 1200 x 2400 dpi | 1200 x 2400 dpi |
| Power Consumption | 18 W | 18 W | 18 W |
| Power Adapter Input | 100-240V AC; 50-60 Hz, 0.6 A |
100-240V AC; 50-60 Hz, 0.6 A |
100-240V AC; 47-63 Hz; 1.35-0.53 A |
| Power Adapter Output | 24 V DC, 0.75 A | 24 V DC, 0.75 A | 24 V DC, 0.75 A |
